GYLD type SF6 dew point tester

Recommended Products
Product Details
          Technical Specifications:


Measuring rang

Dew point value: -80 ℃ ~ + 20

trace moisture value: 0 ~ 19999uL / L

measurement accuracy

± 0.5 ℃ (-60 ℃ ~ + 20 ℃)

± 1.0 ℃ (-80 ℃ ~ -60 ℃)

Resolution

Dew point value: 0.1

trace moisture value: 1uL / L

Response time

(+ 20 ℃, 0.1Mpa)

63% needs 5s, 90% needs 45s (-60 ℃ ~ + 20 ℃)

63% takes 10s, 90% takes 240s (+ 20 ℃ ~ -60 ℃)

Sampling flow

0.6L / min ± 20%

Pressure range

0 ~ 1.0Mpa

Operating temperature

-20 ℃ ~ + 60 ℃

environment humidity

0 ~ 100% RH

storage temperature

-20 ℃ ~ + 80 ℃

Charging time

4 hours

Overall size

250 × 150 × 300mm3

Total Weight

3.5kg

        Product Features:

1. High stability: Under severe interference conditions, the measurement data can be stabilized within

  ± 0.5 ℃, and has excellent long-term stability and good repeatability

2. High precision: It adopts imported high-performance dew point sensor and high-speed 12-bit Σ-ΔAD

   analog-to-digital converter. The highest resolution reaches 0.1 ℃, which fully meets the actual

   measurement requirements. Accurate and reliable measurement results within a full range, wide

   measurement range, fast response speed, stable and reliable measurement results

3. Intelligent: self-calibration at startup, the sensor probe can automatically calibrate the zero point,

   automatically eliminate the system errors introduced by the zero point drift, and ensure the

   accuracy of the measurement

4. Multiple protection: with oil pollution filter device, not affected by dust particles and most chemical pollution,

   it can protect the sensor from oil pollution, which is very suitable for industrial environment.

5. Fast gas saving: After entering the measurement state, the dew point measurement time is 3 to 5 minutes.

6. Powerful function: 4.7-inch true color touch LCD display, full Chinese operation interface. Directly display the

   dew point value (℃), micro water value (uL / L), date and time, and dynamically display the dew point measurement

   curve. Save measurement data in real time, can store up to 100 sets of measurement data

7. Communication function: RS232 interface can be connected with PC serial port, which is convenient
    for PC to further process data

8. Convenient to use: The self-locking connector imported from Japan is used, which is easy to insert and pull,

   safe and reliable, and has no air leakage. The sensitive touch buttons are convenient for operation and improve

   work efficiency. Built-in large-capacity rechargeable lithium battery, small size, light weight, easy to carry
